Application: Widely used in ceramics, chemical industry, electronics, metallurgy, new material development, machinery, refractories, building materials, special materials and other fields of experiment and production.

category

Parameter 1300 degrees

Model KSS-1300

Power supply AC 380V

The position of the heating element is heated on both the left and right sides

Temperature control accuracy ±1℃

Design temperature, temperature 1300℃, working temperature 1300℃

Furnace temperature uniformity ±5℃ (according to the size of the furnace, empty furnace)

Temperature measuring element Type B thermocouple

Construction:

The shell adopts steel profile. Surface spray color carefully matched, pleasing to the eye, heat resistant, anti-corrosion. The circuit design is advanced and reasonable. Furnace body structure Electric furnace body and control cabinet

Heating element silicon carbide rod

Refractory zirconia synthetic material, small heat storage, resistance to acute heating and cooling, no cracks, no slag, good insulation performance (energy saving effect is more than 80% of the old electric furnace)

The insulation material adopts multi-layer insulation, and the energy-saving effect is more than 80% of the old electric furnace.

Furnace shell temperature long-term use without furnace, shell ≤50℃

Protection adopts integrated module control, control accuracy is accurate, and designed double circuit control and double circuit protection, with overshoot, overshoot, undermodulation, segment pair, phase loss, overvoltage, overcurrent, overtemperature, current feedback, soft start protection

The button has a long service life and an indicator light.

Temperature curve setting using intelligent temperature controller, standard PID adjustment mode, with multi-segment program control function, can achieve any slope rise, cooling control, with jump (cycle), run, pause and stop and other programmable/operable commands
